IDA V3 VARIABLE SPEED DRIVE
V3-240041-3F12
1.5 kW • 4.1 A • 380–480 Vac • 3 Phase
IP20 Panel Mount with internal EMC filter and TFT Display
V3-240041-3F12 is a high-performance industrial variable speed drive designed for demanding motor control applications including pumps, fans and process machinery.
The IDA V3 platform provides advanced motor control, flexible programming and reliable operation for OEM and industrial automation applications.
KEY FEATURES
- Advanced motor control capability
- Sensorless vector control
- Permanent magnet motor support
- Integrated PLC functionality
- PID process control
- Programmable digital and analogue I/O
- Modbus RTU communication
- Safe Torque Off (STO)
APPLICATIONS
- Industrial machinery
- Pumps and fans
- HVAC systems
- Compressors
- Conveyors
- Hoists
- Process equipment
TECHNICAL SPECIFICATIONS
Input Ratings| Supply Voltage | 380–480 Vac | | Input Phases | 3 Phase |
Output Ratings| Motor Output Rating | 1.5 kW | | Output Voltage | 400V, 3-ph, 4.1A | | Output Current | 4.1 A | | Output Phases | 3 Phase |
Factory Build Options| Internal EMC Filter | Yes | | Internal Brake Transistor | No | | Enclosure | IP20 Panel Mount | | Display | TFT Display | | PCB Coating | Standard Localised Coating |
Cable Information| Maximum Supply Cable Size | 8 mm² | | Maximum Motor Cable Size | 8 mm² | | Maximum Motor Cable Length | 100 m |
| Control & Communications| Sensorless Vector Control | Yes | | Permanent Magnet Motor Support | Yes | | Integrated PLC | Yes | | PID Control | Yes | | Communications | Modbus RTU |
Drive Dimensions| Frame Size | Size 2 | | Height | 221 mm | | Width | 110 mm | | Depth | 185 mm | | Weight | 1.8 kg | | Fixings | 4 × M4 |
Packaged Dimensions| Packaged Height | 265 mm | | Packaged Width | 145 mm | | Packaged Depth | 230 mm | | Packaged Weight | 1.9 kg |
|
OEM reference: ODV-3-240041-3F12-MN
