Energy Efficient Indoor Rated IP55, 160kW, 3Ph. In, 3Ph. Out, 380-480V
Details
+
Details
+
IDA V3 VARIABLE SPEED DRIVE
V3-743020-3F1N
160 kW • 302 A • 380–480 Vac • 3 Phase
IP55 Indoor with internal EMC filter and TFT Display
V3-743020-3F1N is a high-performance industrial variable speed drive designed for demanding motor control applications including pumps, fans and process machinery.
The IDA V3 platform provides advanced motor control, flexible programming and reliable operation for OEM and industrial automation applications.
KEY FEATURES
- Advanced motor control capability
- Sensorless vector control
- Permanent magnet motor support
- Integrated PLC functionality
- PID process control
- Programmable digital and analogue I/O
- Modbus RTU communication
- Safe Torque Off (STO)
APPLICATIONS
- Industrial machinery
- Pumps and fans
- HVAC systems
- Compressors
- Conveyors
- Hoists
- Process equipment
TECHNICAL SPECIFICATIONS
Input Ratings
Output Ratings
Factory Build Options
Cable Information
| Control & Communications
Drive Dimensions
Packaged Dimensions
|
Recommended Accessories & Options
RJ45 Accessories6
IDA-T2-J4505
T2-J4505
RS485 Data Cable, RJ45, 0.5 m
IDA-T2-J4510
T2-J4510
RS485 Data Cable, RJ45, 1.0 m
IDA-T2-J4530
T2-J4530
RS485 Data Cable, RJ45, 3.0 m
IDA-T2-J45SP
T2-J45SP
RS485 Data Cable Splitter, RJ45, 3-Way, 3 x Female Ports
IDA-T2-RJHUB
T2-RJHUB
RS485 Network Hub, RJ45, 8-Way
IDA-T2-RJTRM
T2-RJTRM
RS485 Network Terminator, RJ45
Communication Interfaces11
IDA-T2-BNTIP
T2-BNTIP
Communication Module, BACnet/IP, Plug-in Option Slot
IDA-T2-DEVNT
T2-DEVNT
Communication Module, DeviceNet, Plug-in Option Slot, CIP Parameter Object, 4 In / 4 Out Words
IDA-T2-ETCAT
T2-ETCAT
Communication Module, EtherCAT, Plug-in Option Slot, CANopen over EtherCAT (DS301), 2-Port
IDA-T2-ETHEG
T2-ETHEG
IDA EtherNet/IP Interface
IDA-T2-ETHNT
T2-ETHNT
Communication Module, EtherNet/IP, Plug-in Option Slot, 2-Port, CIP Parameter Object
IDA-T2-MODIP
T2-MODIP
Communication Module, Modbus TCP, Plug-in Option Slot, 2-Port, 10/100 Mbit, Galvanically Isolated
IDA-T2-PFNET
T2-PFNET
Communication Module, PROFINET IO, Plug-in Option Slot
IDA-T2-PROFB
T2-PROFB
Communication Module, PROFIBUS DP, Plug-in Option Slot, DPV-1 Parameter Access, 9.6 kbps to 12 Mbps
IDA-T2-USB485-OBUS
T2-USB485-OBUS
IDA USB PC Connection Kit
IDA-T3-PFNET
T3-PFNET
Communication Module, PROFINET IO, Plug-in Option Slot, MRP Client
IDA-T3-STICK
T3-STICK
IDA Commissioning Tool
I/O Options3
IDA-T2-CASCD
T2-CASCD
Cascade Control Module, Plug-in, 3 Relay Outputs, DOL Pump Cascade to 4 Pumps
IDA-T2-EXTIO
T2-EXTIO
Extended I/O Module, Plug-in Option Slot, 3 Digital Inputs and 1 Relay Output (250 V AC, 5 A)
IDA-T2-PTXIN
T2-PTXIN
Temperature Input Module, PT100/PT1000, 2-Channel, Plug-in Option Slot
